DESCRIPTION

• Designed for long-lasting industrial use

• Fast color changes with minimum solvent consumption

• Simple design to minimize maintenance time and operation

▶ Technical manual

Performance

• 1 Quiet and balanced air motor for constant delivery

• 1 There is minimal pulsation due to quick air motor change over at low air pressures

• 2 Stainless-steel fluid section compatible with a wide range of materials including water-based paints

• 3 Designed to eliminate dead zones for quick color changes

• Pulse-free for a superior finish

• Able to flush and prime at very low air pressures (0.6 bar/8.5 psi)

Productivity

• 3 Large foot valve to handle high viscosity materials up to 5,000 cPs - carbide seat

• 4 Small fluid section, minimal material loss during color changes

• 5 Closed construction decreases the risk of injuries and protects the lubricant from external contamination

• 5 Leak indicator weep hole for fast visual inspection

• 6 Easy rotating outlet fitting to fit various configurations

Sustainability

• 1 Stall-free Differential Air Motor won't ice up

• 3 Easy to service with direct access to the suction valve

• 4 Single piece built-in cartridge with no dead zone

• 6 Easy coupling for a quick disassembling

• Mobile seal located on the piston ensures the cleaning of the fluid section internal wall while the pump is in operation

• Low maintenance, no external air distributor assembly. 45% fewer parts vs competition

• Triple chrome-plated piston parts compatible with most materials

• Magnetic reversing valve to eliminate pump surge

• Reduced spare parts: 50% fewer parts vs competition
